Application Visibility shows which applications guests actually use once they’re on the network. It surfaces traffic classification from the Cisco Service Gateway — distinguishing web browsing from video conferencing from streaming, for example — and lets you see how bandwidth is being spent. Typical uses:
  • Capacity planning — see which applications drive the most traffic and size uplinks accordingly.
  • Policy tuning — if a single class of traffic dominates, consider adjusting Access Policies or bandwidth controls at the network layer.
  • Abuse detection — unexpected long-running sessions for categories you don’t expect at a venue (peer-to-peer file sharing in an office, for example).
Application Visibility dashboard

​
Requirements

  • Service Gateway deployment. Application Visibility reads its classification data from the Service Gateway’s deep-packet inspection. Meraki-only integrations do not produce this data.
  • Licensing on the Service Gateway. The underlying Cisco platform may require specific feature licenses to perform traffic classification. Coordinate with your Service Gateway provisioning.

​
What it shows

Application Visibility dashboards typically show:
  • Top applications by volume over a configurable time window.
  • Category breakdowns — web, video, audio, cloud storage, social, etc.
  • Per-venue splits when combined with Site-based redirects or multi-site deployments.
  • Time-of-day patterns — when traffic peaks.
The exact visualisations depend on your Service Gateway version and configuration.

​
What it doesn’t do

Application Visibility is observational, not enforcement:
  • It does not block applications. That’s a Service Gateway policy layer, configured separately.
  • It does not identify individual users — it aggregates traffic across active sessions.
  • It does not replace a SIEM or a dedicated traffic analytics tool for security investigations.
Think of it as situational awareness — a fast way to understand where bandwidth goes at a venue.

​
Relationship to Statistics and Exports

The broader Statistics and Exports feature tracks who signed in. Application Visibility tracks what they did with the connection. The two complement each other.
